| Frame |
4130 double butted crmo, TA, rack / fender mounts, internal light cable routing, 73 mm BSA BB shell |
| Fork |
4130 crmo, double butted blades, TA, 1.1/2'' - 1.1/8'', fender / rack / triple cage mounts, internal hub dynamo cable routing |
| Handlebar |
BOMBTRACK BEYOND travel bar, 31.8 mm, 30° flare |
| Grips |
BOMBTRACK COMMAND bar tape |
| Stem |
BOMBTRACK WANDER forged aluminium stem, +17° |
| Headset |
Sealed external aheadset, 1.1/2'' - 1.1/8'' |
| Levers |
SRAM Apex double tap mechanic |
| Shifter |
SRAM Apex double tap 2 x 10 |
| Brakes |
TRP SPYRE C mechanic disc brakes with 180 mm F / 160 mm R rotors |
| Crankset |
BOMBTRACK AMES forged aluminium crank, 24 mm spindle |
| BB |
BSA sealed BB, external cups |
| Pedals |
- |
| Chain |
KMC X10 chain, 1/2'' x 11/128'', 114L |
| Chainring |
Aluminium / Steel, 40 / 28 T |
| Cassette |
SRAM PG-1020 10-speed, 11 - 36 T |
| Front derailleur |
Microshift FD-M612-B |
| Rear derailleur |
SRAM GX, long cage |
| Front hub |
BOMBTRACK GRAD sealed hub, 6-bolt disc |
| Rear hub |
BOMBTRACK ARC sealed hub, 11-speed, 6-bolt disc |
| Through axle |
15 x 100 mm / 12 x 142 mm |
| Front rim |
WTB ST i23 double wall, TCS 2.0, 32h |
| Rear rim |
WTB ST i23 double wall, TCS 2.0, 32h |
| Saddle |
BOMBTRACK ORIGIN saddle |
| Seat post |
BOMBTRACK BEECH 27.2 mm x 400 mm |
| Seat clamp |
BOMBTRACK ORIGIN 29.8 mm |
| Front tire |
WTB RANGER TCS LIGHT / FAST ROLLING XS - S 27.5'' x 2.0'' / M - XL 29'' x 2.0'', tubeless ready |
| Rear tire |
WTB RANGER TCS LIGHT / FAST ROLLING XS - S 27.5'' x 2.0'' / M - XL 29'' x 2.0'', tubeless ready |
| Fender |
- |
| Rack |
- |
| Light |
- |
| Weight |
12.9 kg (size M) |
| Weight frameset |
2540 g frame (size M, incl. TA, bolts, seatclamp, hanger) / 1500 g fork (300 mm steerer, incl. TA) |
| Maximum rider weight |
140 kg incl. luggage |
| ASTM riding condition |
2 |
